21.5 inches Digital Self-Service Kiosk Hardware
Product Details:
- Bluetooth NO
- Screen Size 21.5 Inch (in)
- Processor Type High
- Screen Resolution Adjustable
- Monitor LED
- Connectivity Options Normal
- Click to View more
X
21.5 inches Digital Self-Service Kiosk Hardware Price And Quantity
- 1000 Unit
21.5 inches Digital Self-Service Kiosk Hardware Product Specifications
- LED
- Adjustable
- Normal
- High
- 21.5 Inch (in)
- NO
21.5 inches Digital Self-Service Kiosk Hardware Trade Information
- Cash in Advance (CID)
- 20000 Unit Per Month
- 7-10 Days
- Asia Australia Central America North America South America Eastern Europe Western Europe Middle East Africa
- All India
Product Description
The 21.5 inches Digital Self-Service Kiosk Hardware features a LED monitor with adjustable screen resolution, providing clear and sharp display. With normal connectivity options, this kiosk hardware offers seamless integration with various systems. The 21.5-inch screen size ensures optimal viewing for users. Equipped with a high processor type, this kiosk hardware delivers efficient performance for various self-service applications.
| KS-5X21(Series) | ||||
| Model | KS-5121 | KS-5521 | KS-5821 | |
| Core Logic | Processor | ARM Rockchip RK3288 Quad-core Cortex-A17 up to 1.8GHz | Intel Bay Trail-D Celeron J1900 Quad Core (2M Cache, up to 2.42 GHz) | Intel Core i3 7100U (3M Cache, 2.40 GHz) Intel Core i5 7200U (3M Cache, up to 3.1 GHz) |
| Memory | 2GB DDR3L 1333 | up to 8G DDR3L SO-DIMM | up to 32G DDR4 SO-DIMM | |
| Storage | 16GB eMMC + 1 x microSD Card (up to 128GB) | 1 x M.2 M Key Slot | 1 x M.2 M Key Slot | |
| LCD Panel | Panel Size | 21.5-inch VA LED Panel | 21.5-inch VA LED Panel | 21.5-inch VA LED Panel |
| Resolution | 1080 (V) x 1920 (H) | 1080 (V) x 1920 (H) | 1080 (V) x 1920 (H) | |
| Brightness | 250nits | 250nits | 250nits | |
| View Angle | 89 / 89 / 89 / 89 | 89 / 89 / 89 / 89 | 89 / 89 / 89 / 89 | |
| Touch Panel | Bezel Free | True-Flat PCAP Touch (G+G) | True-Flat PCAP Touch (G+G) | True-Flat PCAP Touch (G+G) |
| RF Communication | Wi-Fi / 4G LTE | Wi-Fi IEEE 802.11 b/g/n | Option | Option |
| Speaker | Internal Speaker | 2 x 5W Speakers | 2 x 5W Speakers | 2 x 5W Speakers |
| I/O Interface | ||||
| External I/O | USB | 2 x USB 2.0 type A | 2 x USB 2.0 type A | 2 x USB 2.0 type A |
| LAN | 1 x RJ45 Ethernet (Host) 1 x RJ45 Ethernet (option : EMV Payment) | 1 x RJ45 Ethernet (Host) 1 x RJ45 Ethernet (option : EMV Payment) | 1 x RJ45 Ethernet (Host) 1 x RJ45 Ethernet (option : EMV Payment) | |
| Power Cord Socket | 1 x AC Male Power Socket | 1 x AC Male Power Socket | 1 x AC Male Power Socket | |
| Power Switch | 1 x Power Switch Button | 1 x Power Switch Button | 1 x Power Switch Button | |
| Mechanical & Environmental | ||||
| Surface Color Plan | Standard or Customizable by project | Standard or Customizable by project | Standard or Customizable by project | |
| Brand Logo | Customizable by project | Customizable by project | Customizable by project | |
| Dimension (W x H x D in mm) | Main System Only : 350.2 x 824.4 x 116 mm Floorstanding ( Stand 02) : 600 x 1650 x 400 mm | Main System Only : 350.2 x 824.4 x 116 mm Floorstanding ( Stand 02) : 600 x 1650 x 400 mm | Main System Only : 350.2 x 824.4 x 116 mm Floorstanding ( Stand 02) : 600 x 1650 x 400 mm | |
| Weight(N. W. in KG) | Main System Only : 20KG Floorstanding Version (w/ Satnd 02) : 47KG | Main System Only : 20KG Floorstanding Version (w/ Satnd 02) : 47KG | Main System Only : 20KG Floorstanding Version (w/ Satnd 02) : 47KG | |
| Operation System | OS | Android 7.1 | Win 10 IoT Ent | Win 10.1 IoT Ent |
| Environment | Operation Condition | 0C to +35C / 20 to 80% without condensation | 0C to +35C / 20 to 80% without condensation | 0C to +35C / 20 to 80% without condensation |
| Storage Condition | -5C to +55C / 20 to 85% without condensation | -5C to +55C / 20 to 85% without condensation | -5C to +55C / 20 to 85% without condensation | |
| Optional Accessories | ||||
| Visual Recognition | 5M-Pixel AF Full HD Camera | 5M-Pixel AF Full HD Camera | 5M-Pixel AF Full HD Camera | |
| Thermal Printer | 2" or 3" standalone thermal printer with cutter 203 dpi and Max. 200 mm/s supported | 2" or 3" standalone thermal printer with cutter 203 dpi and Max. 200 mm/s supported | 2" or 3" standalone thermal printer with cutter 203 dpi and Max. 200 mm/s supported | |
| Mini QR Code Scanner | Fixed mount barcode scanner, 800 x 800 CMOS, White LED Scan modes : Sense mode, Continuous mode Optimized to read barcode from a mobile phone screen | Fixed mount barcode scanner, 800 x 800 CMOS, White LED Scan modes : Sense mode, Continuous mode Optimized to read barcode from a mobile phone screen | Fixed mount barcode scanner, 800 x 800 CMOS, White LED Scan modes : Sense mode, Continuous mode Optimized to read barcode from a mobile phone screen | |
| Large QR Code Scanner | Fixed mount barcode scanner, 1280 x 1088 CMOS, Red LED Scan mode : Advanced Sense mode Optimized to read barcode from a mobile phone screen | Fixed mount barcode scanner, 1280 x 1088 CMOS, Red LED Scan mode : Advanced Sense mode Optimized to read barcode from a mobile phone screen | Fixed mount barcode scanner, 1280 x 1088 CMOS, Red LED Scan mode : Advanced Sense mode Optimized to read barcode from a mobile phone screen | |
| MSR/IC Card Combo Reader | Based on customer requirements | Based on customer requirements | Based on customer requirements | |
| NFC/RFID Reader | Based on customer requirements | Based on customer requirements | Based on customer requirements | |
| EMV Payment Device Bracket | Based on customer requirements | Based on customer requirements | Based on customer requirements | |
| More Optional | Wi-Fi IEEE 802.11 b/g/n Stand 01 (w/o Indoor Wheels) Stand 02 (w/ Indoor Wheels) Stand 03 (w/ Base Plate) Wall Mount Bracket Kit Multiple Holder (Supermarket Version) | Wi-Fi IEEE 802.11 a/b/g/n/ac (Mini-PCIe) or 4G LTE Module (Mini-PCIe) Stand 01 (w/o Indoor Wheels) Stand 02 (w/ Indoor Wheels) Stand 03 (w/ Base Plate) Wall Mount Bracket Kit Multiple Holder (Supermarket Version) | Wi-Fi IEEE 802.11 a/b/g/n/ac (M.2 E Key) 4G LTE Module (Mini-PCIe) Stand 01 (w/o Indoor Wheels) Stand 02 (w/ Indoor Wheels) Stand 03 (w/ Base Plate) Wall Mount Bracket Kit Multiple Holder (Supermarket Version) | |
FAQs of 21.5 inches Digital Self-Service Kiosk Hardware:
Q: What is the screen size of the Digital Self-Service Kiosk Hardware?
A: The screen size of the Digital Self-Service Kiosk Hardware is 21.5 inches.Q: Does the kiosk hardware have Bluetooth connectivity?
A: No, the kiosk hardware does not have Bluetooth connectivity.Q: Can the screen resolution be adjusted?
A: Yes, the screen resolution of the kiosk hardware is adjustable.Q: What type of processor does the kiosk hardware have?
A: The kiosk hardware is equipped with a high processor type.Q: What are the connectivity options available with the kiosk hardware?
A: The kiosk hardware has normal connectivity options for seamless integration.Tell us about your requirement
